  2. MBASS Metal Insulation Fixing 8 x 250mm, Stainless Steel, Class A1 Fire Rating - cardboard box - 125 pcs.

Universal
Outlet

MBA-SS-08250

5906675049939

Fire-resistant metal insulation fixing

Download model Perform the calculations

Define product parameters:

Material type
Length
Packaging and quantity
Weight and bulk packaging

  • Unit pack

    125.00 pcs.4.53 kg

  • Bulk pack

    125.00 pcs.4.53 kg

This product has been withdrawn from sale.

Related products

Rawlplug SDS Plus Rebar Drill Bit 16 x 150 x 210mm, PGM Approved - plastic hanger - 1 pc.

Brickdrill SDS PLUS non-impact drill bits 8.0x460 m - plastic hanger - 1 pc.

18 V RawlHAMMER 2.0J 20mm Cordless rotary hammer drill, Set with RawlCASE, 2 batteries 5.0Ah and 6.5 A RawlCHARGER - plastic case - 1 pc.

Dead blow hammer 0,6 kg - label - 1 pc.

Rawlplug SDS Plus Drill Bit 8.0 x 400 x 460mm, 2 Cutter, PGM Approved - plastic hanger - 1 pc.

Rebardrill SDS Plus drill bits 16x100x160 mm - plastic hanger - 1 pc.

Counterbore cutter for EPS and mineral wool 90x20 mm - cardboard box - 1 pc.

MKC-SS Stainless Steel Retaining Metal Flanges For MBASS Fixings - cardboard box - 250 pcs.

Rawlplug SDS Plus Rebar Drill Bit 16 x 150 x 210mm, PGM Approved - plastic hanger - 1 pc.

Brickdrill SDS PLUS non-impact drill bits 8.0x460 m - plastic hanger - 1 pc.

18 V RawlHAMMER 2.0J 20mm Cordless rotary hammer drill, Set with RawlCASE, 2 batteries 5.0Ah and 6.5 A RawlCHARGER - plastic case - 1 pc.

Dead blow hammer 0,6 kg - label - 1 pc.

Rawlplug SDS Plus Drill Bit 8.0 x 400 x 460mm, 2 Cutter, PGM Approved - plastic hanger - 1 pc.

Rebardrill SDS Plus drill bits 16x100x160 mm - plastic hanger - 1 pc.

Counterbore cutter for EPS and mineral wool 90x20 mm - cardboard box - 1 pc.

MKC-SS Stainless Steel Retaining Metal Flanges For MBASS Fixings - cardboard box - 250 pcs.

Features

Fire-resistant metal insulation fixing

  • Accessory spreader plate, MKC-SS (85mm diameter) also available for installation of soft insulation materials such as mineral wool.
  • Metal facade fixing, recommended for use when fire resistance (F120) is a requirement.
  • Extensive dimensional range allows anchorage of insulation boards up to 250mm thick.
  • Fast and simple hammer-set installation reduces working times.
  • Stainless steel material for high corrosion resistance.

R_MBA_monta_zag__bionywwe_niemineralnej

R_MBA_monta_powierzchniowywwe_niemineralnej

Krok_po_kroku_jak_montowac_kolki_fasadowe_z_trzpieniem_wbijanym

Concrete C20/25-C50/60 (A)

Concrete C20/25-C50/60 (A)

Solid brick (B)

Solid brick (B)

Solid sand-lime brick (B)

Solid sand-lime brick (B)

Ceramic hollow block

Ceramic hollow block

Aerated concrete

Aerated concrete

Aerated concrete block (D)

Aerated concrete block (D)

Hollow sand-lime brick ≥ 15MPa

Hollow sand-lime brick ≥ 15MPa

Approved surfaces

Facades - thermal insulation systems

Material type
Length
Packaging and quantity
Index
EAN
Catalog price for pack. net

Installation manual

Installation step by step

1

Drill hole to the required diameter and depth for rebar size being usee

2

Blow out dust at least 3 times with a hand pump.

3

Gently drive the MBA steel connector (with MKI plate) into the hole until the connector is anchored to the correct depth.

4

Correctly installed steel facade fixing.

5

Cut the hole in insulation board.

6

Drill a hole of appropriate diameter and depth.

7

Clean drilled hole 3 times.

8

Gently drive the steel dowel into the hole until the correct anchorage depth for the fastener is achieved. For soft substrates, use the MKC 85 mm steel washer.

9

Insert cap into countersunk hole in insulation board following installation of the facade fixing.

10

Correctly installed steel facade fixing.
