Vinylester bonded anchor R-KER standard - plastic cartouche - 400 ml

Solid walls

R-KER-400

5906675329444

Polyester bonded anchor without styrene, recommended for medium loads, for use in concrete

Define product parameters:

Bonded anchors version
Packaging and quantity

Related products

Manual gun for bonded anchor resin in cartridges 175-310ml - label - 1 pc.

Professional manual gun for bonded anchors.

Pump for blowing drill cuttings - plastic bag - 1 pc.

Manual blow pump for cleaning dust from drilled holes

Manual gun for cartridges: 385/600ml(3:1), 280/300/310ml, 380-410ml (10:1), 4.5kN - cardboard box - 1 pc.

Professional manual gun for resin anchors in cartridges 385/600ml(3:1), 280/300/310ml, 380-410ml (10:1), 4,5kN

Metal brush for cleaning holes M12 - label - 1 pc.

Metal brush with handle for cleaning holes in a solid substrate

Rebardrill SDS Plus drill bits 18x250x310 mm - plastic hanger - 1 pc.

High-quality SDS plus drill bits for drilling in reinforced concrete

Metric threaded rod, hexagonal head, steel class 8.8 STUDS 16x190mm - cardboard box - 10 pcs.

Threaded rod made of class 8.8 steel for use with bonded anchors

18 V RawlHAMMER 2.0J 20mm Cordless rotary hammer drill, Set with RawlCASE, 2 batteries 5.0Ah and 6.5 A RawlCHARGER - plastic case - 1 pc.

18V SDS plus Cordless hammer drill "RawlHammer"

Aggressor SDS Plus drill bits 18x250x310 mm - plastic hanger - 1 pc.

Drill bits SDS plus for fast drilling in concrete

Metric threaded rod, hexagonal head, steel class 8.8 STUDS 20x260mm - cardboard box - 5 pcs.

Threaded rod made of class 8.8 steel for use with bonded anchors

Turbodrill SDS Max drill bit 24x200x340 mm - plastic hanger - 1 pc.

SDS max drill for drilling deep holes in reinforced concrete, concrete, stone and hard brick

Metric threaded rod, hexagonal head, steel A4 STUDS 20x260mm - cardboard box - 5 pcs.

Threaded rod made of A4 stainless steel for use with bonded anchors

Rebardrill SDS Max drill bit 18x200x340 mm - plastic hanger - 1 pc.

SDS max drill with 3 symmetrically arranged cutting edges allow, for drilling holes in reinforced concrete, concrete, stone and hard brick

Features

Polyester bonded anchor without styrene, recommended for medium loads, for use in concrete

  • Suitable for use in dry and wet substrates including under water
  • Approved for use in cracked and non-cracked concrete (EAD 330499-00-0601)
  • Very high load capacity
  • Suitable for repetitive use. Partly used product can be reused fitting a new mixing nozzle
  • Anchor does not generate expansion forces in the concrete which means reduced spacing and edge distances.
  • Approved for use in non-cracked concrete
  • Approved for use with post-installed rebars in non-cracked concrete
  • Suitable for variable anchor embedment depths.
  • Suitable for multiple use. Partly used product can be reused after fitting new nozzle
  • Allows removal of bolt to leave a re-usable socket in place

Product video

Jak prawidłowo użyć kotwy chemicznej?

Jaką kotwę chemiczną wybrać?

Czym jest kotwa chemiczna i jak jej używać?

Kotwy chemiczne winyloestrowe do stosowania przez cały rok – zastosowanie i tutorial Rawlplug

Rawlplug R-KER Vinylester Resin - Rebar Installation

Rawlplug CFS+ RV200 Styrene Free Vinylester Resin - Cartridge Free System

Substrates

Cracked concrete C20/25-C50/60

Cracked concrete C20/25-C50/60

Non-cracked concrete C20/25-C50/60

Non-cracked concrete C20/25-C50/60

Approved surfaces

Applications

Anchoring glued in with reinforcing bars

Anchoring glued in with threaded rods

Balustrades

Barriers

Concrete structures

Electrical Installations

Elevators and escalators

Formwork

Gates

Handrails

Pipelines

Pitched roofs

Reinforcement of a large slab

Sanitary and gas installations

Steel structures

Ventilated facades

Services

Resin calculator

Resin calculator

EasyFix

EasyFix

Training at the Rawlplug Academy center

Training at the Rawlplug Academy center

Design Consulting

Design Consulting

Installation guide

Installation manual

Installation step by step

1

Blow out the dust at least 4 times with the hand pump.

2

Drill a hole to the required diameter and depth for rebar size being used.

3

Clean drilled hole 4 times.

4

Remove drill cuttings from the hole using the hand pump four times.

5

Place the cartridge in the dispenser.

6

Dispense to waste until even colour is obtained.

7

Fill with resin 70% of the depth of the hole, starting from the bottom of the hole.

8

Immediately after dispensing the resin, insert the rod into the hole with a twisting motion.

9

Remove the unnecessary amount of resin that flowed from the hole and wait for the appropriate time for the resin to cure.

10

Immediately insert the rebar, slowly and with slight twisting motion. Remove any excess resin around the hole before it sets and leave it undisturbed until the curing time elapses.

11

Place the bar in the hole and allow the setting time to elapse.

12

Attach fixture and tighten the nut to the required torque.

13

Drill a hole of appropriate diameter and depth.

14

Wydmuchać pył co najmniej 4 razy przy pomocy ręcznej pompki.

15

Usunąć zwierciny z otworu za pomocą czterokrotnego użycia wyciora

16

R_KEX_385_stud_inst_draw_04

17

Umieścić kartridż w dozowniku i przymocować dyszę mieszającą

18

Rozpoczynając dozowanie z nowego opakowania odrzucić część żywicy, aż do uzyskania jednakowego koloru mieszanki

19

Insert the mixing nozzle to the far end of the hole and inject resin, slowly withdrawing the nozzle as the hole is filled to 70% of its depth.

20

Immediately after dispensing the resin, insert the rod into the hole with a twisting motion.

21

Leave the anchor undisturbed unitl the curing time elapses.

22

Reinforcing bar is properly installed in the concrete base.
