KI-10 Hammer-in facade fixing with plastic pin 10x90 mm - cardboard box - 250 pcs.

Universal

R-KI-090

5906675258188

Rawlplug

Hammer-in facade fixing with reinforced plastic nail

Define product parameters:

Length
Packaging and quantity

Related products

Rebardrill SDS Plus drill bits 8x150x210 mm - plastic hanger - 1 pc.

High-quality SDS plus drill bits for drilling in reinforced concrete

Rebardrill SDS Plus drill bits 8x200x260 mm - plastic hanger - 1 pc.

High-quality SDS plus drill bits for drilling in reinforced concrete

Insulation retaining plate R-KWL 140 mm, polyamide - cardboard box - 200 pcs.

Insulation retaining plate for use in combination with facade fixings from TFIX and KI ranges

KWL Insulation retaining plate 90 mm, PP - cardboard box - 200 pcs.

Insulation retaining plate for use in combination with facade fixings from TFIX and KI ranges

Insulation retaining plate R-KWL 90 mm, polyamide - cardboard box - 200 pcs.

Insulation retaining plate for use in combination with facade fixings from TFIX and KI ranges

Aggressor SDS Plus drill bits 8x150x210 mm - plastic hanger - 1 pc.

Drill bits SDS plus for fast drilling in concrete

Aggressor SDS Plus drill bits 8x200x260 mm - plastic hanger - 1 pc.

Drill bits SDS plus for fast drilling in concrete

Brickdrill SDS PLUS non-impact drill bits 8.0x260 m - plastic hanger - 1 pc.

Drill bits for non-impact drilling in ceramic materials

Polystyrene cap KES - 63x20 mm white - cardboard box - 250 pcs.

Thermal insulation cap reduces heat transmission and results in a homogenous insulation surface

18 V RawlHAMMER 2.0J 20mm Cordless rotary hammer drill, Set with RawlCASE, 2 batteries 5.0Ah and 6.5 A RawlCHARGER - plastic case - 1 pc.

18V SDS plus Cordless hammer drill "RawlHammer"

Counterbore plastic cutter for EPS and mineral wool KFS 63x23,5 mm - cardboard box - 1 pc.

Cutter accessory for counterbored installation of TFIX hammer-in facade insulation fixings

Polystyrene cap KES - 63x20 mm gray - cardboard box - 250 pcs.

Thermal insulation cap reduces heat transmission and results in a homogenous insulation surface

Features

Hammer-in facade fixing with reinforced plastic nail

  • Installation in all base materials (categories A,B,C,D,E)
  • The plastic nail reduces heat transmission (value 0.0 W/K).
  • Plastic nail reinforced with glass fibre allows fast and trouble-free installation with correct expansion of the plug.
  • Expansion zone designed for low embedment depths, reducing the amount of drilling required.
  • Can be used with additional KWL insulation holding plate, available in 90, 110 and 140 mm flange sizes (recommended for soft insulation materials such as mineral wool).
  • Optimal product parameters enable cost-saving solutions.
  • Optimum plate stiffness (0,5 kN/mm), ensures stability and excellent pull-over values.

Substrates

Concrete ≥ C12/15 (Use category A)

Concrete ≥ C12/15 (Use category A)

Solid brick (Use category B)

Solid brick (Use category B)

Solid sand-lime brick (Use category B)

Solid sand-lime brick (Use category B)

Vertically-perforated clay block (Use category C)

Vertically-perforated clay block (Use category C)

Hollow sand-lime brick (Use category C)

Hollow sand-lime brick (Use category C)

Lightweight concrete block

Lightweight concrete block

Hollow lightweight concrete block (Use category D)

Hollow lightweight concrete block (Use category D)

Lightweight concrete

Lightweight concrete

Aerated concrete block (Use category D)

Aerated concrete block (Use category D)

Approved surfaces

Applications

Ventilated facades

Facades - thermal insulation systems

Substitutes

Services

Design Consulting

Design Consulting

EasyFix

EasyFix

E-learning training

E-learning training

Learn more
Rawlplug Academy

Rawlplug Academy

Installation guide

Installation manual

Installation step by step

1

Drill a hole of required diameter and depth. Drilling depth of min 35 mm in masonry, 50 mm in perforated materials and 70 mm in lightweight concrete block and aerated concrete.

2

Blow out dust at least 4 times with a hand pump.

3

Lightly tap the plastic sleeve through the insulation material into hole with a hammer, until fixing depth is reached.

4

Lightly tap the plastic nail into the plastic sleeve until fixing is secure and flush with insulation material. Embedment depth of min 25 mm in masonry, 40 mm in perforated materials and 60 mm in lightweight concrete block and aerated concrete.

5

In soft insulation panels the fixing should be combined with insulation retaining plates KWL 90, 110, 140 mm.

Approvals and publications

Technical library and approvals

Choose document:

ETA-07/0291

1488-CPR-0368/Z

DoP-07/0291 KI-10

UKTA-22/6369

UKTA-DoP-22/6369-KI-10
