  1. Mainpage
  2. HR Scaffolding hook 12x350 mm - label - 1 pc.

Solid walls

K-P3-HR-12350

5906675317915

Koelner

Perfect for scaffolding installation

Define product parameters:

Length
Packaging and quantity
Weight and bulk packaging

  • Unit pack

    10.00 pcs.3.81 kg

  • Bulk pack

    10.00 pcs.3.81 kg

  • Pallet

    540.00 pcs.206.01 kg

Related products

18 V RawlHAMMER 2.0J 20mm Cordless rotary hammer drill, Set with RawlCASE, 2 batteries 5.0Ah and 6.5 A RawlCHARGER - plastic case - 1 pc.

18 V RawlWRENCH 210 Nm Impact driver, Set with RawlCASE, 2 batteries 5.0 Ah and 6.5A RawlCHARGER - plastic case - 1 pc.

Rebardrill SDS Plus drill bits 14x100x160 mm - plastic hanger - 1 pc.

Scaffolding plug HRK 14x100 mm - cardboard box - 25 pcs.

Scaffolding plug HRK 14x135 mm - cardboard box - 25 pcs.

Scaffolding plug HRK 14x70 mm - cardboard box - 25 pcs.

18 V RawlHAMMER 2.0J 20mm Cordless rotary hammer drill, Set with RawlCASE, 2 batteries 5.0Ah and 6.5 A RawlCHARGER - plastic case - 1 pc.

18 V RawlWRENCH 210 Nm Impact driver, Set with RawlCASE, 2 batteries 5.0 Ah and 6.5A RawlCHARGER - plastic case - 1 pc.

Rebardrill SDS Plus drill bits 14x100x160 mm - plastic hanger - 1 pc.

Scaffolding plug HRK 14x100 mm - cardboard box - 25 pcs.

Scaffolding plug HRK 14x135 mm - cardboard box - 25 pcs.

Scaffolding plug HRK 14x70 mm - cardboard box - 25 pcs.

Features

Perfect for scaffolding installation

  • The high-quality weld stops the eye from opening.
  • In order to achieve the maximum load-bearing capacity, nylon plugs should only be used once.
  • Enables the attachment of scaffolding, tension ropes, chains and cables. Thanks to this, the scaffolding moves away from the facade depending on needs.
  • The product should be anchored with the HRK expansion plug.

High-density natural stone

High-density natural stone

Concrete

Concrete

Solid brick

Solid brick

Solid sand-lime brick

Solid sand-lime brick

Vertically-perforated clay block

Vertically-perforated clay block

High-density natural stone

High-density natural stone

Concrete

Concrete

Solid brick

Solid brick

Solid sand-lime brick

Solid sand-lime brick

Vertically-perforated clay block

Vertically-perforated clay block

Approved surfaces

Scaffolding

Length
Packaging and quantity
Index
EAN
Catalog price for pc. net

Installation manual

Installation step by step

1

Drill hole to the required diameter and depth for stud size being used.

2

Blow out dust at least 4 times with a hand pump.

3

Place the HR pin in the hole and press it down.

4

Screw the screw with the hook into the expansion plug placed in base material.

5

The plug and hook are correctly mounted in the concrete.

Installation data
