  2. Expansion plug with countersunk head 8x40 mm - cardboard box - 200 pcs.

Expansion plug with countersunk head 8x40 mm - cardboard box - 200 pcs.

Solid walls

K08L040

5906675293479

Koelner

An easy-to-install expansion plug that achieves exceptionally high parameters in solid substrates

Define product parameters:

Packaging and quantity

Related products

Rebardrill SDS Plus drill bits 5x150x210 mm - plastic hanger - 1 pc.

High-quality SDS plus drill bits for drilling in reinforced concrete

R-WBT Screws for concrete and timber T25 6.1x120 mm zinc flak coating - cardboard box - 100 pcs.

Screw for concrete substrates TX25 head. Shape and type of the thread specially design to allow connecting to concrete and wood.

R-WBT Screws for concrete and timber T25 6.1x75 mm zinc flak coating - cardboard box - 100 pcs.

Screw for concrete substrates TX25 head. Shape and type of the thread specially design to allow connecting to concrete and wood.

R-WBT Screws for concrete and timber T25 6.1x100 mm zinc flak coating - cardboard box - 100 pcs.

Screw for concrete substrates TX25 head. Shape and type of the thread specially design to allow connecting to concrete and wood.

Rebardrill SDS Plus drill bits 5x100x160 mm - plastic hanger - 1 pc.

High-quality SDS plus drill bits for drilling in reinforced concrete

R-WBT Screws for concrete and timber T25 6.1x140 mm zinc flak coating - cardboard box - 100 pcs.

Screw for concrete substrates TX25 head. Shape and type of the thread specially design to allow connecting to concrete and wood.

Rebardrill SDS Plus drill bits 5x50x110 mm - plastic hanger - 1 pc.

High-quality SDS plus drill bits for drilling in reinforced concrete

Cone drill bit for concrete 5x100x160 mm, for adapter - plastic box - 1 pc.

Special tapered drill bits for flat roof fixings

R-WBT Screws for concrete and timber T25 6.1x90 mm zinc flak coating - cardboard box - 100 pcs.

Screw for concrete substrates TX25 head. Shape and type of the thread specially design to allow connecting to concrete and wood.

R-WBT Screws for concrete and timber T25 6.1x200 mm zinc flak coating - cardboard box - 100 pcs.

Screw for concrete substrates TX25 head. Shape and type of the thread specially design to allow connecting to concrete and wood.

Rebardrill SDS Plus drill bits 5x300x360 mm - plastic hanger - 1 pc.

High-quality SDS plus drill bits for drilling in reinforced concrete

R-WBT Screws for concrete and timber T25 6.1x160 mm zinc flak coating - cardboard box - 100 pcs.

Screw for concrete substrates TX25 head. Shape and type of the thread specially design to allow connecting to concrete and wood.

Features

An easy-to-install expansion plug that achieves exceptionally high parameters in solid substrates

  • Suitable for fixing insulation materials to concrete in flat roofs applications in conjunction with R-WO screws.
  • Two-way expansion mechanism provides a strong anchorage in solid base materials.
  • Anti-rotation fins prevent spinning during tightening of the screw.
  • Engineered grip feature for extra holding power.

Substrates

Concrete

Concrete

Approved surfaces

Applications

Flat roofs

Services

Design Consulting

Design Consulting

Technical Support 2

Technical Support 2

Rawlplug Academy

Rawlplug Academy

EasyFix

EasyFix

Installation guide

Installation manual

Installation step by step

1

Drill a hole to the required diameter and depth for rebar size being used.

2

Lightly insert plastic sleeve into insulation material.

3

Using drilling machine, drive the WO screw with K08L040 into substrate until fixing depth is reached.

4

Properly mounted sleeve with K08L040 and the WO screw.

Installation data
