Concrete screw in zinc flake with countersunk head, induction hardened R-HLX-CS-ZF 8/10.4x75 mm - cardboard box - 100 pcs.

Solid walls
Bestseller

R-HLX-08X075-CS-ZF

5906675556543

Induction hardened concrete screw anchor with countersunk head

Define product parameters:

Diameter
Length
Coating
Packaging and quantity
Weight and bulk packaging
  • Unit pack

    100.00 pcs.3.75 kg

  • Bulk pack

    100.00 pcs.3.75 kg

  • Pallet

    25600.00 pcs.960.00 kg

Features

Induction hardened concrete screw anchor with countersunk head

  • The new thread geometry with additional cutting teeth ensures quick and easy installation, also in reinforced concrete C20/25 - C50/60.
  • R-HLX concrete screws can be used in earthquake-prone zones - seismic category C1 and C2.
  • Special anti-corrosion zinc flake coating for increased corrosion resistance.
  • Possibility of installation near the edge of concrete and at short distances from adjacent screws.
  • Induction hardening ensures high surface hardness and high core impact strength.
  • Different head types for any application.
  • Possibility of disassembly and repeated use after verifying thread wear with a tester.
  • The highest parameters in cracked and uncracked concrete C20/25 - C50/60 confirmed in the ETA.
  • Reliable and simple installation.

Product video

R-HLX High performed screwbolt

Rawlplug Academy: czym jest i jak działa kotwa mechaniczna?

Substrates

Cracked concrete C20/25-C50/60

Cracked concrete C20/25-C50/60

Non-cracked concrete C20/25-C50/60

Non-cracked concrete C20/25-C50/60

Reinforced concrete

Reinforced concrete

Unreinforced concrete

Unreinforced concrete

High-density natural stone

High-density natural stone

Approved surfaces

Applications

Construction work

Roads and bridges

Satellite dishes

Seats in public facilities

Steel structures

Storage racks

Balustrades

Full list of variations

Substitutes

Services

Installation guide

Installation manual

Installation step by step

1

Drill the hole with a hammer drill (1a) ) to the required depth according to the table

2

Clean the hole (blow dust at least 4 times with the hand pump). When using a dust-free drill bit (1b), it is not necessary to clean the hole..

3

Screw the concrete screw into the hole using an impact wrench and a suitable impact bit. Tighten until the element is pressed to the surface. Installation using an impact wrench with a tangential impact. Finish screwing in when the screw head is in contact with the element/substrate being fastened. The screw head must not be damaged

4

Possibility to unscrew the fixed anchor to a maximum height of 10mm. In the adjustment process, the permissible thickness of the fastened elements (Tfix) must be observed

5

Screw the concrete screw into the hole with an impact wrench and a suitable impact socket. Tighten until the fixture is clamped to the substrate. Installation with any tangential impact wrench

6

Finish screwing in when the anchor presses the fastened element (substrate). The adjustment procedure can be performed twice

Installation data
Design data
Size6810
Thread diameterd[mm]
7,910,412,7
Hole diameter in substrated0[mm]
6810
Hole diameter in fixturedf[mm]
91214
Wrench sizeT[mm]
T40T50T50
External diameter of washerd[mm]
14,218,521
Max. torque for impact screw driverTimp,max[Nm]
250350650
STANDARD EMBEDMENT DEPTH
Min. hole depth in substrateh0,s[mm]
658595
Real hole depth in substrateh0[mm]
L+10-tfixL+10-tfixL+10-tfix
Min. installation depthhnom,s[mm]
557085
Min. substrate thicknesshmin,s[mm]
80110130
Min. edge distancecmin[mm]
353560
Min. spacingsmin[mm]
353560
REDUCED EMBEDMENT DEPTH
Min. hole depth in substrateh0,r[mm]
507085
Real hole depth in substrateh0[mm]
L+10-tfixL+10-tfixL+10-tfix
Min. installation depthhnom,r[mm]
406075
Min. substrate thicknesshmin,r[mm]
80110120
Min. edge distancecmin[mm]
353560
Min. spacingsmin[mm]
353560
MINIMUM EMBEDMENT DEPTH
Min. hole depth in substrateh0,r[mm]
456065
Real hole depth in substrateh0[mm]
L+10-tfixL+10-tfixL+10-tfix
Min. installation depthhnom,r[mm]
355055
Min. substrate thicknesshmin,r[mm]
80110100
Min. edge distancecmin[mm]
353560
Min. spacingsmin[mm]
353560
Size6810
Nominal ultimate tensile strengthfuk[N/mm2]
800800800
Nominal yield strengthfyk[N/mm2]
640640640
Cross sectional area As[mm2]
24,644,267,9
Elastic section modulusWel[mm3]
17,2441,4275,97
Characteristic bending resistanceM0Rk,s[Nm]
16,639,875,8
Design bending resistanceM[Nm]
13,231,860,6
Size6810
Standard embedment depthhnom[mm]
557085
Reduced embedment depthhnom[mm]
406075
Minimum embedment depthhnom[mm]
355055
MEAN ULTIMATE RESISTANCE
TENSION LOAD NRu,m
UNCRACKED CONCRETE
Standard embedment depth-[kN]
18,9926,3437,85
Reduced embedment depth-[kN]
11,0919,0330,59
Minimum embedment depth-[kN]
8,3216,4418,37
CRACKED CONCRETE
Standard embedment depth-[kN]
10,8812,2426,64
Reduced embedment depth-[kN]
7,1111,5921,53
Minimum embedment depth-[kN]
4,029,8612,93
SHEAR LOAD VRu,m
UNCRACKED CONCRETE
Standard embedment depth-[kN]
10,6719,4729,92
Reduced embedment depth-[kN]
10,6719,4729,92
Minimum embedment depth-[kN]
8,9516,4418,37
CRACKED CONCRETE
Standard embedment depth-[kN]
10,6719,4729,92
Reduced embedment depth-[kN]
7,8119,4729,92
Minimum embedment depth-[kN]
6,311,5712,93
CHARACTERISTIC RESISTANCE
TENSION LOAD NRk
UNCRACKED CONCRETE
Standard embedment depth-[kN]
13,820,627,58
Reduced embedment depth-[kN]
813,8722,29
Minimum embedment depth-[kN]
4,511,913,39
CRACKED CONCRETE
Standard embedment depth-[kN]
3,51119,3
Reduced embedment depth-[kN]
2915,6
Minimum embedment depth-[kN]
289,37
SHEAR LOAD VRk
UNCRACKED CONCRETE
Standard embedment depth-[kN]
9,717,727,2
Reduced embedment depth-[kN]
8,0817,727,2
Minimum embedment depth-[kN]
6,5211,9813,39
CRACKED CONCRETE
Standard embedment depth-[kN]
9,717,727,2
Reduced embedment depth-[kN]
5,6617,727,2
Minimum embedment depth-[kN]
4,578,399,37
DESIGN RESISTANCE
TENSION LOAD NRd
UNCRACKED CONCRETE
Standard embedment depth-[kN]
9,213,7318,39
Reduced embedment depth-[kN]
5,339,2514,86
Minimum embedment depth-[kN]
37,938,93
CRACKED CONCRETE
Standard embedment depth-[kN]
2,337,3312,87
Reduced embedment depth-[kN]
1,33610,4
Minimum embedment depth-[kN]
1,335,336,25
SHEAR LOAD VRd
UNCRACKED CONCRETE
Standard embedment depth-[kN]
7,7614,1621,76
Reduced embedment depth-[kN]
5,3914,1621,76
Minimum embedment depth-[kN]
4,357,998,93
CRACKED CONCRETE
Standard embedment depth-[kN]
6,4714,1621,76
Reduced embedment depth-[kN]
3,7712,9520,81
Minimum embedment depth-[kN]
3,045,596,25
RECOMMENDED LOAD
TENSION LOAD Nrec
UNCRACKED CONCRETE
Standard embedment depth-[kN]
6,579,8113,14
Reduced embedment depth-[kN]
3,816,6110,62
Minimum embedment depth-[kN]
2,145,676,38
CRACKED CONCRETE
Standard embedment depth-[kN]
1,675,249,19
Reduced embedment depth-[kN]
0,954,297,43
Minimum embedment depth-[kN]
0,953,814,46
SHEAR LOAD Vrec
UNCRACKED CONCRETE
Standard embedment depth-[kN]
5,5410,1115,54
Reduced embedment depth-[kN]
3,8510,1115,54
Minimum embedment depth-[kN]
3,115,716,38
CRACKED CONCRETE
Standard embedment depth-[kN]
4,6210,1115,54
Reduced embedment depth-[kN]
2,699,2514,86
Minimum embedment depth-[kN]
2,173,994,46
Size6810
Nominal embedment depthhnom[mm]
354055506070557585
Effective embedment depthhef[mm]
263043394356425968
TENSION LOAD
STEEL FAILURE
Characteristic resistanceNRk,s[kN]
19,419,419,435,435,435,454,354,354,3
Partial safety factorγMS[-]
1,51,51,51,51,51,51,51,51,5
PULL-OUT FAILURE
Characteristic resistance in uncracked concrete C20/25NRk,p,ucr[kN]
4,5813,811,916,320,613,422,327,6
Characteristic resistance in cracked concrete C20/25NRk,p,cr[kN]
223,589119,415,619,3
Installation safety factorγinst[-]
1,01)1,01)1111111
Increasing factors for concrete C30/37Ψc[-]
1,171,171,171,171,171,171,221,221,22
Increasing factors for concrete C40/50Ψc[-]
1,321,321,321,321,321,321,411,411,41
Increasing factors for concrete C50/60Ψc[-]
1,421,421,421,421,421,421,551,551,55
CONCRETE CONE FAILURE
Installation safety factorγinst[-]
1,01)1,01)1111111
Factor for cracked concretekcr,N[-]
7,77,77,77,77,77,77,77,77,7
Factor for uncracked concretekucr,N[-]
111111111111111111
Spacingscr,N[mm]
7890129117129168126177204
Edge distanceccr,N[mm]
394564,558,564,5846388,5102
CONCRETE SPLITTING FAILURE
Installation safety factorγinst[-]
1,01)1,01)1111111
Spacingscr,sp[mm]
8090130120150170120180200
Edge distanceccr,sp[mm]
4045656075856090100
SHEAR LOAD
STEEL FAILURE
Characteristic resistance without lever armVRk,s[kN]
9,79,79,717,717,717,727,227,227,2
Ductility factork7[-]
111111111
Characteristic resistance with lever armMRk,s[Nm]
16,116,116,139,839,839,875,875,875,8
Partial safety factorγMS[-]
1,251,251,251,251,251,251,251,251,25
CONCRETE PRY-OUT FAILURE
Factork[-]
111122122
Installation safety factorγinst[-]
111111111
CONCRETE EDGE FAILURE
Effective length of anchorℓf[mm]
354055506070557585
Anchor diameterdnom[mm]
666888101010
Installation safety factorγinst[-]
111111111
1) Holes without cleaning γinst = 1,2
Size6810
R (for EI) = 30 min
Nominal embedment depthhnom[mm]
354055506070557585
TENSION LOAD
STEEL FAILURE
Characteristic resistanceNRk,s[kN]
1,81,81,83,83,83,86,66,66,6
PULL-OUT FAILURE
Characteristic resistanceNRk,p[kN]
0,50,50,822,22,72,33,94,8
SHEAR LOAD
STEEL FAILURE
Characteristic resistance without lever armVRk,s[kN]
1,81,81,83,83,83,86,66,66,6
Characteristic resistance with lever armMRk,s[Nm]
1,51,51,54,34,34,39,39,39,3
R (for EI) = 60 min
Nominal embedment depthhnom[mm]
354055506070557585
TENSION LOAD
STEEL FAILURE
Characteristic resistanceNRk,s[kN]
1,41,41,42,92,92,9555
PULL-OUT FAILURE
Characteristic resistanceNRk,p[kN]
0,50,50,822,22,72,33,94,8
SHEAR LOAD
STEEL FAILURE
Characteristic resistance without lever armVRk,s[kN]
1,41,41,42,92,92,9555
Characteristic resistance with lever armMRk,s[Nm]
1,21,21,23,33,33,3777
R (for EI) = 90 min
Nominal embedment depthhnom[mm]
354055506070557585
TENSION LOAD
STEEL FAILURE
Characteristic resistanceNRk,s[kN]
1112223,43,43,4
PULL-OUT FAILURE
Characteristic resistanceNRk,p[kN]
0,50,50,822,22,72,33,94,8
SHEAR LOAD
STEEL FAILURE
Characteristic resistance without lever armVRk,s[kN]
1112223,43,43,4
Characteristic resistance with lever armMRk,s[Nm]
0,80,80,82,32,32,34,84,84,8
R (for EI) = 120 min
Nominal embedment depthhnom[mm]
354055506070557585
TENSION LOAD
STEEL FAILURE
Characteristic resistanceNRk,s[kN]
0,80,80,81,61,61,62,62,62,6
PULL-OUT FAILURE
Characteristic resistanceNRk,p[kN]
0,40,40,71,61,82,21,83,13,8
SHEAR LOAD
STEEL FAILURE
Characteristic resistance without lever armVRk,s[kN]
0,80,80,81,61,61,62,62,62,6
Characteristic resistance with lever armMRk,s[Nm]
0,70,70,71,81,81,83,73,73,7
Size6810
Nominal embedment depthhnom[mm]
4055506070557585
SEISMIC CATEGORY C1
TENSION LOAD, STEEL FAILURE
Characteristic resistanceNRk,s,C1[kN]
19,419,435,435,435,454,354,354,3
TENSION LOAD, PULL-OUT FAILURE
Characteristic resistance seismic C1NRk,p,C1[kN]
23,57,68,610,58,614,417,8
SHEAR LOAD, STEEL FAILURE
Characteristic resistance without lever armVRk,s,C1[kN]
4,74,710,610,610,618,718,718,7
SEISMIC CATEGORY C2
TENSION LOAD, STEEL FAILURE
Characteristic resistanceNRk,s,C2[kN]
----35,4--54,3
TENSION LOAD, PULL-OUT FAILURE
Characteristic resistance seismic C2NRk,p,C2[kN]
----2--8,5
SHEAR LOAD, STEEL FAILURE
Characteristic resistance without lever armVRk,s,C2[kN]
----3,6--8

Approvals and publications

Technical library

(8)

Technical assessments(2)

ETA-23/0707 (2025-01-24) - Cracked and uncracked concrete

R-HLX - Concrete screw for use in cracked and uncracked concrete

ETA-24/1104 (2025-06-03) - Non-structural systems

Concrete screw for use in concrete for redundant non-structural systems

Declarations(2)

DoP-23/0707 R-HLX (ETA-23/0707)

DoP-23/0707 R-HLX (ETA-23/0707 - 2025-01-24) - Concrete screw for use in cracked and uncracked concrete

DoP-24/1104-R-HLX (ETA-24/1104 - Non-structural systems)

R-HLX - Cpncrete screw for use in concrete for redundant non-structural systems.

Certificates(3)

1488-CPR-1100/W (ETA-23/0707)

CPR (ETA-23/0707 - 2025-01-24) - Concrete screw for use in cracked and uncracked concrete

1488-CPR-0745/Z (ETA-24/1104 - Non-structural systems)

CPR - ETA-24/1104 (2025-06-03) - Non-structural systems

EPD-R-HLX (2025-11-27)

Type III Environmental Declaration Certificate

Documents(1)

VDS CEA 4001 (2025-03-05)

Pipe hanger components for automatic sprinkler systems

Catalogues and product cards

(5)

Product cards(2)

Product card R-HLX hollow-core slab

Product card

Catalogues(3)

Catalogue Offer (overview) - EN

Specification Design Guide

General Catalogue EN 2026/27

Stay up to date

Sign up for our newsletter and don't miss:

Information

on our products and services

News

on the offering and latest promotions

Reports

on events, trade shows and industry conferences

© 2026 Koelner Rawlplug IP
