  1. Mainpage
  2. R-HPTIIIZP Throughbolt M8 x 85mm, Zinc Plated - cardboard box - 100 pcs.

Solid walls
New

R-HPTIIIZP08085/35

5906675525648

Stainless steel - cardboard throughbolt anchor for cracked and non-cracked concrete

Download model Perform the calculations

Define product parameters:

Diameter
Washer
Length
Coating
Packaging and quantity
Weight and bulk packaging

  • Unit pack

    100.00 pcs.3.28 kg

  • Bulk pack

    100.00 pcs.3.28 kg

  • Pallet

    12000.00 pcs.418.24 kg

Related products

Pump for blowing drill cuttings - plastic bag - 1 pc.

Rawlplug SDS Plus Rebar Drill Bit 8.0 x 150 x 210mm, PGM Approved - plastic hanger - 1 pc.

SDS plus RawlHAMMER 850 W 2.5J 26 mm Rotary hammer drill - plastic case - 1 pc.

Aggressor SDS Plus drill bits 8x150x210 mm - plastic hanger - 1 pc.

Rawlplug SDS Plus Rebar Drill Bit 8.0 x 100 x 160mm, PGM Approved - plastic hanger - 1 pc.

RT-IS Impact Socket CR-MO -13 x 18mm - plastic hanger - 1 pc.

18 V RawlHAMMER 2.0J 20mm Cordless rotary hammer drill, Set with RawlCASE, 2 batteries 5.0Ah and 6.5 A RawlCHARGER - plastic case - 1 pc.

Aggressor SDS Plus drill bits 8x100x160 mm - plastic hanger - 1 pc.

150mm fi 18.6mm tool for mechanical anchors, SDS plus - plastic hanger - 1 pc.

R-PGL Protective gloves for power tools 10" blue - paper hanger - 1 pc.

R-HTW-20-100 Torque spanner 20-100 Nm 1/2" - cardboard box - 1 pc.

Locksmith's hammer 0.8 kg - label - 1 pc.

Pump for blowing drill cuttings - plastic bag - 1 pc.

Rawlplug SDS Plus Rebar Drill Bit 8.0 x 150 x 210mm, PGM Approved - plastic hanger - 1 pc.

SDS plus RawlHAMMER 850 W 2.5J 26 mm Rotary hammer drill - plastic case - 1 pc.

Aggressor SDS Plus drill bits 8x150x210 mm - plastic hanger - 1 pc.

Rawlplug SDS Plus Rebar Drill Bit 8.0 x 100 x 160mm, PGM Approved - plastic hanger - 1 pc.

RT-IS Impact Socket CR-MO -13 x 18mm - plastic hanger - 1 pc.

18 V RawlHAMMER 2.0J 20mm Cordless rotary hammer drill, Set with RawlCASE, 2 batteries 5.0Ah and 6.5 A RawlCHARGER - plastic case - 1 pc.

Aggressor SDS Plus drill bits 8x100x160 mm - plastic hanger - 1 pc.

150mm fi 18.6mm tool for mechanical anchors, SDS plus - plastic hanger - 1 pc.

R-PGL Protective gloves for power tools 10" blue - paper hanger - 1 pc.

R-HTW-20-100 Torque spanner 20-100 Nm 1/2" - cardboard box - 1 pc.

Locksmith's hammer 0.8 kg - label - 1 pc.

Features

Stainless steel - cardboard throughbolt anchor for cracked and non-cracked concrete

  • Optimized cone shape, increasing the rake angle floor straps.
  • Identification mark of anchor length, facilitating control after installation.
  • Two kinds washers DIN 125, DIN 9021.
  • Depth marker facilitating the installation anchors in the hole.
  • High performance in cracked and non-cracked concrete confirmed by ETA Option 1.
  • Steel expansion band with optimized design, providing secure anchoring.
  • Thickness of fastened elements can be increased thanks to high carrying capacity and shallow depth anchoring.
  • Can be used for fastening steel/ aluminum and wooden elements.
  • Software support for designing fasteners EasyFix anchoring.
  • Application specification in accordance with EAD 330232-01-0601 and included in ETA-21/1082.

R-HPTIII Throughbolt

Rawlplug Academy: czym jest i jak działa kotwa mechaniczna?

Cracked concrete C20/25-C50/60

Cracked concrete C20/25-C50/60

Non-cracked concrete C20/25-C50/60

Non-cracked concrete C20/25-C50/60

Unreinforced concrete

Unreinforced concrete

Reinforced concrete

Reinforced concrete

Approved surfaces

Balustrades

Barriers

Elevators and escalators

Seats in public facilities

Steel structures

Storage racks

Ventilated facades

Diameter
Washer
Length
Coating
Packaging and quantity
Index
EAN
Catalog price for pack. net

R-HPTIIZF Throughbolt M8 x 80mm, Zinc Flake - cardboard box - 100 pcs.

Zinc flake throughbolt with large washer R-HPTII-ZF 8x80 mm - cardboard box - 100 pcs.

R-HPTIIZF Throughbolt M8 x 80mm, Zinc Flake - cardboard box - 100 pcs.

Zinc flake throughbolt with large washer R-HPTII-ZF 8x80 mm - cardboard box - 100 pcs.

Installation manual

Installation step by step

1

Drill a hole to the required diameter and depth for rebar size being used.

2

Blow out the dust at least 4 times with the hand pump.

3

Lightly tap the throughbolt through the fixture into hole with a hammer, until fixing depth is reached.

4

Using a torque wrench, tighten the nut to the required torque.

5

The anchor is correctly fixed.

Installation data

Technical library

(6)

Technical assessments(1)

ETA-21/1082 (2024-04-26)

Download
Declarations(1)

DoP-21/1082-R-HPTIII-ZP - ETA-21/1082 (2024-04-26)

Download
Certificates(2)

1488-CPR-1062/W - ETA-21/1082 (2024-04-26)

Download

EPD R-HPTIII-ZP (2025-10-01)

Download
Documents(2)

VDS CEA 4001 (2025-03-05)

Download

FM approval PR458139 (2024-01-15)

Download
