Zinc plated Internally Threaded M10 concrete screw anchor R-LX-I-ZP 6x55 mm - label - 1 pc.

Solid walls
Outlet

R-P3-LX-06X55I10ZP

5906675432243

Self-tapping concrete screwbolt

Define product parameters:

Diameter
Length
Coating
Thread
Packaging and quantity

Related products

Features

Self-tapping concrete screwbolt

  • Non-expansion functioning ensures low risk of damage to base material and makes R-LX ideal for installation near edges and adjacent anchors
  • Suitable for standard and reduced embedment depth
  • Time-efficient installation through streamlined procedure - simply drill and drive
  • Unique design with patented threadform ensures high performance for relatively small hole diameter
  • High performance in non-cracked concrete
  • Excellent product for temporary fixing
  • Completely removable
  • Oversize head for fixtures with elongated holes
  • Different head types for any application

Product video

Rawlplug R-LX mechanical concrete screw anchor - tutorial and principle of operation

Mechanical concrete screw anchor – Rawlplug's instruction

Substrates

Cracked concrete C20/25-C50/60

Cracked concrete C20/25-C50/60

Non-cracked concrete C20/25-C50/60

Non-cracked concrete C20/25-C50/60

Unreinforced concrete

Unreinforced concrete

Reinforced concrete

Reinforced concrete

Hollow-core slab C30/37-C50/60

Hollow-core slab C30/37-C50/60

High-density natural stone

High-density natural stone

Cracked concrete C20/25-C50/60

Cracked concrete C20/25-C50/60

Non-cracked concrete C20/25-C50/60

Non-cracked concrete C20/25-C50/60

Unreinforced concrete

Unreinforced concrete

Reinforced concrete

Reinforced concrete

Approved surfaces

Applications

Balustrades

Concrete structures

Formwork

Gates

Scaffolding

Seats in public facilities

Storage racks

Temporary fixings

Services

Design Consulting

Design Consulting

Training at the Rawlplug Academy center

Training at the Rawlplug Academy center

EasyFix

EasyFix

Technical library

Technical library

Installation guide

Installation manual

Installation step by step

1

Drill a hole to the required diameter and depth for rebar size being used.

2

R_LX_I_2_hollow

3

Tighten the anchor into the ground to the required torque.

4

Install the fixture.

5

The anchor is properly fixed in the concrete base.

Installation data

Approvals and publications

Technical library and approvals

Choose document:

ETA 17/0783

DoP-17/0783 R-LX

UKTA-22/6346

Product card and catalogues

Choose product card:

Product card

Choose product catalog:

Specification Design Guide

General catalogue - PDF
