  1. Mainpage
  2. RoofSystem cone drill bits for reinforced concrete, for adapter 5x100x160 mm - plastic box - 1 pc.

Solid walls

RT-TDR-50-160

5906675389707

Rawlplug

Special tapered drill bits for flat roof fixings

Define product parameters:

Diameter
Length
Working length
Packaging and quantity
Weight and bulk packaging

  • Unit pack

    1.00 pcs.0.04 kg

  • Bulk pack

    400.00 pcs.18.47 kg

  • Pallet

    7200.00 pcs.332.51 kg

Related products

R-WBT Screws for concrete and timber T25 6.1x90 mm zinc flak coating - cardboard box - 100 pcs.

18 V RawlHAMMER 2.0J 20mm Cordless rotary hammer drill, Set with RawlCASE, 2 batteries 5.0Ah and 6.5 A RawlCHARGER - plastic case - 1 pc.

18 V RawlHAMMER 2.0J 20mm Cordless rotary hammer drill, without batteries and RawlCHARGER - cardboard box - 1 pc.

RoofSystem SDS Plus adapter 500 mm - plastic box - 1 pc.

18 V RawlHAMMER 2.0J 20mm Cordless rotary hammer drill, Set with RawlCASE, without batteries and RawlCHARGER - plastic case - 1 pc.

RoofSystem SDS Plus adapter 800 mm - plastic box - 1 pc.

RoofSystem SDS Plus adapter 1000 mm - plastic box - 1 pc.

R-WBT Screws for concrete and timber T25 6.1x90 mm zinc flak coating - cardboard box - 100 pcs.

18 V RawlHAMMER 2.0J 20mm Cordless rotary hammer drill, Set with RawlCASE, 2 batteries 5.0Ah and 6.5 A RawlCHARGER - plastic case - 1 pc.

18 V RawlHAMMER 2.0J 20mm Cordless rotary hammer drill, without batteries and RawlCHARGER - cardboard box - 1 pc.

RoofSystem SDS Plus adapter 500 mm - plastic box - 1 pc.

18 V RawlHAMMER 2.0J 20mm Cordless rotary hammer drill, Set with RawlCASE, without batteries and RawlCHARGER - plastic case - 1 pc.

RoofSystem SDS Plus adapter 800 mm - plastic box - 1 pc.

RoofSystem SDS Plus adapter 1000 mm - plastic box - 1 pc.

Features

Special tapered drill bits for flat roof fixings

  • 3 symmetrically arranged cutting edges allow for perfectly straight and axial drilling.
  • Angle tip 135° allows drilling in reinforced concrete.
  • 3 material extraction surfaces and special shape of the drill facilitate the removal of dust.
  • The conical connection between drill and an SDS plus adapter allows the transfer of 100% of impact.
  • Very deep seating of carbide plate significantly improves connection with the drill core, which affects quality.
  • Steel with specification 34CrNiMo6 provides high strength and durability.
  • Monolithic carbide tip increases the life of the drill bit.
  • Heat treated, which increases the hardness of the steel to 52 HRC for optimal resistance during operation.

High-density natural stone

High-density natural stone

Concrete

Concrete

Reinforced concrete

Reinforced concrete

Solid brick

Solid brick

Approved surfaces

Concrete structures

Flat roofs

Pitched roofs

Diameter
Length
Working length
Packaging and quantity
Index
EAN
Catalog price for pc. net

Cone drill bits 5x50x110 mm for reinforced concrete, for adapter - plastic box - 1 pc.

Cone drill bits 5x50x110 mm for reinforced concrete, for adapter - plastic box - 1 pc.
